75 HP
55 kW

LOVOL TB754N

75 HP in a narrow 1,398 mm frame for orchards and vineyards
Orchards, vineyards, tunnels, narrow-row crops and confined spaces
Download brochure
Request a quote
75 HP
Rated power
8F + 8R
Transmission
32 L/min
Hydraulic flow
Stage II
Emission

Overview

The LOVOL TB754N packs 75 HP into a narrow 1,398 mm-wide chassis, making it ideal where space is tight but real power is still required. A simple 8F+8R synchronized transmission and mechanical drivetrain keep it easy to operate and maintain.

Just 1,398 mm wide for tight rows and tunnels
8F+8R synchronized shift, easy to operate
Adjustable rear track from 1,020 to 1,320 mm

Gallery

Specifications

Horsepower
75 HP
Engine model
Xinchai A4K43T75, 4.32 L, 4-cyl
Emission standard
Stage II
Gears
8F + 8R
Shift mode
Synchronized shift
Speed range
2.24 to 26.22 km/h
Hydraulic flow
32 L/min
Wheelbase
2,535 mm
Structure weight
2,040 kg (ROPS)
Front wheels
8.3-20
Rear wheels
14.9-24
Max operating mass
2,320 kg (ROPS)
